| Depth: |
4 1/2" dia bore holes to a depth of 100mtr(300ft) using 3" drill rod |
|
6 1/2" dia bore holes to a depth of 80mtr(240ft) using 3" drill rod |
| Prime mover: |
Engine of 90hp for all opration. |
|
Max capacity- 6tons(13227lbs) |
|
Rod handling 1.5mtr (5ft) |
| Hydraulic system: |
Hydraulic pressur : 154kg/cm2 (2200psi) |
|
Pull up speed : 8.5 mtr / min (28ft / min) |
|
Pull up force : 2694kg (5926 lbs) |
|
Pull down force : 1814kg (3990 lbs) |
|
Pull down speed : 12.5 mtr/min (48ft / min) |
| Rotary head: |
Miximum torque 146kg-mtrs(12740 inch-lbs) |
| Jack: |
Four hydraulic leveling jack for proper levling drill point with seprate lever |
| Suitable compressor: |
450cfm@150psi ; 450cfm@175psi; 600cfm@200psi |
